Technical Specifications
Image Sensor
Sensor Type
High Definition Color CMOS Sensor
Display Resolution
5.0Megapixels(3072*1728)
Min. Illumination
0 Lux (With IR Illuminator)
Lens
Lens Type
f:4mm; F2.1
Angle of view
Diagonal: 107.9°, Horizontal: 91.6°, Vertical: 49.6°
Video
Resolution
5MP(3072*1728) 1.5M/25 fps,1080P(1920*1080)1M/25fps, 720P(1280*720)1M/15fps
Stream
Dual stream
Image Adjustment
The hue, brightness, contrast, saturation, sharpness are adjustable
Flip Image
Flip and mirror
Night Mode
Manual and automatic modes, when the white light is on, the night vision image is colored
Night Visibility
With 4pcs IR-LED and spotlight, Night Vision Range up to 20m
Audio
Input/Output
Built-in mic and speaker,support full duplex 2-way Audio
Audio Compression
PCM/AAC
Siren
Support maximum 100dB alarm siren
Network
Ethernet
One 10/100Mbps RJ45 port
Remote Access
P2P
Network Protocol
IP, TCP, UDP, SMTP, FTP, DHCP, RTSP
System Requirements
Operating System
Microsoft Windows (Foscam VMS), MacOS (Foscam VMS), Android (Foscam app), iOS (Foscam app)
Other Features
Motion Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
Vehicle Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
Human Detection
Alarm via E-Mail, FTP and Foscam app when an event is detected
WDR
Improve image clarity in complex scenarios
Zoom
20X digital zoom function
Storage
Support max. 256GB Micro SD card, local and FTP storage, Foscam cloud storage
Intelligent Assistant
Supports Alexa, Google Home
Power
Power Supply
DC 12V/1.0A (Not included)
Power Consumption
5Watts (Max.)
Environment
Waterproof
IP66
Operating Temperature
-20°C ~ 50°C (-4°F ~ 122°F)
Operating Humidity
10% ~ 80% non-condensing
Storage Temperature
-20°C ~ 60°C (-4°F ~ 140°F)
Storage Humidity
0% ~ 90% non-condensing
Certification
-
FCC, CE, RoHS, IP66
